Clarke ENCORE S17 - Gearbox Assembly and Parts List 5;03

Page -50- Clarke
®
Operator's Manual -Encore S17/L17
Clarke
®
Encore S17/L17 Rotary Disk
Gearbox Assembly and Parts List 5/03
Ref # Part No. Description Qty
1 57846A Ring, Snap 1
2 507641 Seal, Oil, Small 1
3 52050A Cap End 1
4 56668A O-Ring 1
5 51176A Bearing, Large 1
7 902605 Bearing, Small 1
9 58144A Seal, Oil Large 1
10 NI Darina EP2 Grease 4 oz.
11 52855A Complete Gearbox Asm. 1
1
2
3
4
5
7
8
