Operator's Manual - Encore S17/L17 Page -41-
Ref. # Part No. Description Qty
1 80196A Nut, M5 x .8, Nylock 1
2 87036A Washer, Flat #10 1
3 61305A Tube Bracket 1
4 80199A Nut, M6 x 1, Nylock 2
5 80198A Nut, M8 x 1.25, Nylock 2
6 980652 Washer, Lock 5/16" 1
7 80195A Screw, M6 x 1 x 20mm, Hex Head 4
8 87026A Washer, Flat 1/4" 2
9 61292A Pin Bracket 1
10 61296A Squeegee Arm 1
11 980651 Washer, Flat 5/16" 2
12 80194A Screw, M8 x 1.25 x 30mm, Hex Head 1
13 80101A Screw, 1/4-20 x 3 1/4" 1
14 61461A Squeegee Swivel Spacer 1
15 60256A Pivot Bracket 1
16 80197A Screw, M8 x 1.25 x 20mm, Hex Head 1
17 81104A Nut, 1/4-20 Nylock 1
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
Squeegee Lift Parts List 11/02
