PARTS LIST
01/2015 RA40 - 9100000394 101
ACTUATORS SYSTEM
Revised 07/2017
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
K2 1 2 NUT.M8
K1 2 5 WASHER M6 UNI6592
K1 3 5 SCREW M6X12 UNI5931 SS
K2 4 2 SCREW M8X50 UNI5931 THREADED TOTALLY
5 9100001126 1 SUPPORT DECK ACTUATOR SIP SEE TSB-FC-2016-007
6 9100001131 1 ACTUATOR 24V DC STROKE 98MM SIP
K2 7 1 WASHER M8 UNI6592
K1 8 2 SCREW CYL HD 5X20 SELF L. PLASTOFAST
9 9100001103 1 SUPPORT SQUEEGEE ACTUATOR SIP UNTIL S/N 3510163404520
9# 9100001754 1 SUPPORT SQUEEGEE ACTUATOR GALV. SIP STARTING FROM S/N 3510163404521
10 9100001133 1 ACTUATOR 24V DC STROKE 77.5MM SIP
K2 11 1 PIN SQUEEGEE ACTUATOR
K2 12 1 PIN SPLIT 2X50 UNI8833
K1 13 1 SCREW M6X12 UNI5931
14# 9100002105 1 CAP D.9 PLASTIC 10 PCS SET SEE TSB-FC-2016-021
[K1]# 9100001663 1 HARDWARE ACTUATOR SUPPORT KIT
[K2] 9100001173 1 HARDWARE ACTUATOR KIT
