Clarke RA40 User Manual

INSTRUCTIONS FOR USE ENGLISH
9100000394 - RA40 9
01/2015
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
– GEL/AGM batteries
– Brushes of different materials
– Pads of different materials
– Squeegee blades of different materials
– Filling hose
– Detergent Mixing System
– Pivoting light
– Mop a trash kit
– USB port
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Model RA40
Solution tank capacity 18.5 US gal (70 liters)
Recovery tank capacity 18.5 US gal (70 liters)
Machine length
50 in (1,270 mm)
Machine width with squeegee
28.3 in (720 mm)
Machine width without squeegee
21.6 in (550 mm)
Machine height
40.1 in (1,020 mm)
Turning space for U-turns
71 in (1,800 mm)
Cleaning width
21 in (530 mm)
Rear driving wheel diameter 10 in (254 mm)
Rear driving wheel specic pressure on the oor 145 psi (1.0 N/mm
2
)
Front steering wheel diameter 7.9 in (200 mm)
Front wheel specic pressure on the oor 188 psi (1.3 N/mm
2
)
Brush/pad diameter
21 in (530 / 508 mm)
Brush pressure with extra-pressure function turned off 33 lb (15 kg)
Brush pressure with extra-pressure function turned on 66 lb (30 kg)
Solution ow values 0.75 cl/m / 1.5 cl/m / 3.0 cl/m / (2.8 l/min, if enabled)
Detergent Mixing System detergent percentage (optional) 0,5 / 1 / 2 / 3 Oz/Gal (0,4 / 0,75 / 1,5 / 2,5 %)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
68 ± 3 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) 130 in/s
2
(3.3 m/s
2
)
Vibration level at the operator’s body (ISO 5349-1, EN 60335-2-72) 35.4 in/s
2
(0.9 m/s
2
)
Maximum gradient when working
2 %
Drive system motor power
0.53 hp (400 W)
Drive speed (variable)
0 - 3.7 mi/h (0 - 6 km/h)
Vacuum system motor power
0.4 hp (310 W)
Vacuum system circuit capacity
39 in H
2
O (1,000 mm H
2
O)
Brush motor power
0.6 hp (450 W)
Brush motor speed
155 rpm
Total absorbed power
26 A (620 W)
IP protection class X4
Protection class (electric) III (I for the battery charger)
Battery compartment size 13.8x14.2x11 in (350x360x280 mm)
System voltage 24V
Standard batteries (2) Discover 12V-105Ah
Battery charger 100-240Vac 50-60Hz, 24Vdc 13A
Work autonomy (standard batteries)
2.5 hour
Weight without batteries and with empty tanks
267 lb (121 kg)
Gross vehicle weight (GVW)
754 lb (342 kg)
Shipping weight
342 lb (155 kg)
revised 07/2017
9100000394(D)07-2017.indb 9 21/06/2017 11:54:53
