ENGLISH INSTRUCTIONS FOR USE
12 RA40 - 9100000394
01/2015
BEFORE MACHINE START-UP
WARNING!
When starting the machine, or before operating the “One Touch” button (42), make sure that there is no foreign
material between the deck and the tank assembly which could obstruct the deck movement. If the machine has
been turned off without lifting the deck, the deck would lift automatically at next machine start-up.
Brush or pad-holder removal/installation
According to the kind of cleaning to be performed, the machine
can be equipped either with the brush (A, Fig. 2) or the pad-
holder (B) with pad (C) together with the appropriate deck.
1. Place the brush (A) or the pad-holder (B) under the deck
(7).
2. Turn the ignition key (41) to “I”.
3. Press the push-button (42) to lower the deck on the brush.
4. To engage the brush, press the drive pedal (2) shortly, if
necessary repeat the procedure until the brush is engaged.
5. To remove the brush, lift the deck by pressing the push-
button (42), then manually release the brush from the hub
by turning it abruptly in its normal rotation direction (D).
B
A
C
D
Figure 2
P100864
Available brushes and their relevant application guides (suggestions only)
Models 46 GRIT 80 GRIT 180 GRIT 240 GRIT 500 GRIT PROLENE PROLITE UNION MIX
General cleaning:
Concrete
Terrazzo oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing:
Rubber tiles
Marble
Vinyl tiles
