PARTS LIST
01/2015 RA40 - 9100000394 83
SOLUTION TANK SYSTEM
Revised 07/2017
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
1 9098329000 1 HINGES KIT
2 9100000803 1 VALVE ELBOW SIP
3 9100000574 1 FITTING STRAIGHT G1/2 D.20 KIT
4 1465355000 1 CAP SOLUTION TANK KIT
5*# 9100001353 1 FILTER SOLUTION TANK SIP
6* 9100000952 1 FILLING HOSE (9100001072) INSTALLATION INSTRUCTIONS
8# 9100001855 1 TANK SOLUTION 70 LT PLAST. BLUE KIT UNTIL S/N 3510163405520
8# 9100001854 1 TANK SOLUTION 70 LT PLAST. BLUE SIP
9 9100001102 1 COVER BATTERY CHARGER SIP
10 9100001120 1 HARNESS TANK SIP
11# 9100001578 1 HOSE FRESH WATER LEVEL KIT (9100000968) INSTALLATION INSTRUCTIONS
12 9100001129 1 SUPPORT F SAFETY BAR SIP
13 9100001164 1 CLAMP HOSE D.40 BLACK KIT
14 9100001139 2 GASKET RUBBER D.21X33X2.5 BLACK SIP
15 9100001182 1 COVER FUNCTIONS CARD KIT
16 9100001150 1 PROTECTION RUBBER ADHESIVE F TANK SIP
17 9100001370 1 O-RING F. HEPA/ULPA FILTER SIP
9100000394(D)07-2017.indb 83 21/06/2017 11:55:47
