PARTS LIST
01/2015 RA40 - 9100000394 85
RECOVERY TANK SYSTEM
Revised 07/2017
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
1
9100000817 1 BALL FLOATING SIP
K1 2 1 CAGE FLOAT
3# 9100001348 1 CLAMP 14/32-52 10 PCS SET
4 9100001130 1 CUSHION SEAT W. MICROSWITCH SIP
K1 5 2 SCREW M6X20 ISO7380 SS
K1 6 9100000928 1 GASKET FLOAT SUPPORT SIP
K1 7 2 NUT JAW M6X6 INOX SS
8
9100000818 1 CAGE FLOAT HALF 2 PCS SET
9 9100001091 1 TRAY DEBRISE SIP
10 9100001092 1 COVER TRAY DEBRISE SIP
12 909 6380 000 1 CLAMP KIT
13 9100001135 1 TANK RECOVERY 70 LT BLUE SIP
14 9100001106 1 HOSE SUCTION BLACK SIP
15# 9100001511 1 COVER RECOVERY TANK KIT
16 9100001113 1 HOSE DRAIN BLACK SIP
K2 17 1 BAR SAFETY F TANK
K2 18 1 PLATE F SAFETY BAR
19*
909 5065 000 1 FILTER ANTIFOAMING
K2 20 4 SCREW M6X12 ISO7380
21 9100001164 1 CLAMP HOSE D.40 BLACK
22 9100001143 1 SOUNDPROOFING UPPER VACUUM MOT. SIP
23 9100001181 1 MOTOR VACUUM 24V 310W KIT
K1 24 2 WASHER 6X18X1.5 UNI6593 SS
25 9100001146 1 PLATE HARNESS PROTECTION SIP
26 9100001154 1 HOSE CORRUGATED BLACK D.6 L.150MM SIP
K3 27 1 MOTOR GASKET LOWER DOMEL
K3 28 1 FILTER
29 9100000822 1 SUPPORT INT. INSULATION VAC. MOTOR SIP
30 9100001116 1 HARNESS VACUUM MOTOR SIP
K3 31 1 GASKET F VACUUM UPPER COVER
K3 32 1 GASKET F VACUUM LOWER COVER
33 9100001142 1 SOUNDPROOFING VACUUM MOTOR SIP
34 9100001144 1 MOTOR VACUUM 24V 310W SIP
K3 35 1 RUBBER SEALING DOMEL UPPER
[K1]# 9100001875 1 SUPPORT FLOAT KIT
[K2] 9100001165 1 BAR SAFETY F TANK KIT
[K3] 9100001166 1 GASKETS VACUUM MOTOR KIT
