INSTRUCTIONS FOR USE ENGLISH
9100000394 - RA40 7
01/2015
MACHINE STRUCTURE (Continues)
22. Battery charger
23. Serial number plate/technical data/conformity certication
24. Rear driving wheels
25. Solution tank ller neck
26. Recovery water drain hose
27. Container with debris collection grid
28. Vacuum grid with automatic shut-off oat
29. Recovery water tank cover (open)
30. Squeegee vacuum hose
31. Squeegee support wheel
32. Squeegee mounting handwheels
33. Squeegee adjusting knob
34. Brush deck bumper wheel
35. Tank assembly and seat lifting handle
36. Tank assembly and seat support rod
37. Batteries (*)
38. Detergent Mixing System tank (*)
39. Electronic component compartment cover
40. Lifted recovery tank assembly and driver’s seat
(*) Optional
23
35
22
34
24
29
373839
4036
28
27
26
25
30
32
33
32
31
P100877
