PARTS LIST
01/2015 RA40 - 9100000394 89
CHASSIS SYSTEM
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
K1 1 2 WASHER 10X30 UNI6593
K2 2 1 SCREW M12X16 UNI5739
K1 3 4 NUT SELF L. M10 UNI7473
K2 4 1 WASHER 12X48X3 UNI6593
5 9100001090 2 ROD EYE M10 SIP
K1 6 6 SPACER D.10.5X14X3MM
7 9100001096 1 SLEEVE SUCTION HOSE SIP
8 9100001108 1 SUPPORT SQUEEGEE SIP
K2 9 1 SPRING ZERO SETTING SQUEEGEE
10# 9100002236 1 HARNESS MACHINE SIP
11# 9100002410 1 HARNESS FOOTBOARD F BLUE LINE SIP
12 9100001183 1 MICROSWITCH KIT
13 9100001180 1 THROTTLE KIT
14 9100001140 1 THROTTLE ELECTRONIC SIP
15# 9100002234 1 FUSE BOLT DOWN 50A SIP
16# 9100002235 2 HOLDER FUSE SIP
[K1] 9100001167 1 HARDWARE SAFETY BAR KIT
[K2] 9100001168 1 SPRING ZERO SETTING SQUEEGEE KIT
Revised 07/2017
