Clarke RA40 - Page 93

PARTS LIST
01/2015 RA40 - 9100000394 91
MOTOR DRIVE SYSTEM
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
K1 1 2 WASHER 8.5X32X2 SS
K1 2 2 CAP D.38.1
3 9100001162 1 WHEEL D.254X80 GREY-BLACK 2 PCS SET
K1 4 10 SCREW M8X20 UNI5739 SS
5# 9100001351 1 WASHER M8 UNI6592 SS10 PCS SET
6# 9100001346 1 RING D 20 UNI7435 10 PCS SET
7 9100001156 1 KEY JOINT 6X30 UNI6604A 10 PCS SET
8
9100001161 1 SPACER 20.5X25X4 10 PCS SET
9 9100001099 1 MOTOR DRIVE 400W 24V 125RPM SIP
10 9100001198 1 BAND METAL F ELECTRIC MOTOR FIXING KIT
11 9100001199 1 ELECTROMAGNETIC BRAKE SIP
12 9100001200 1 MOTOR ELECTRIC 400W 24V SIP
13 1464432000 1 CARBON BRUSHES KIT 4 PCS
14# 9100002418 1 CHAIN ANTISTATIC KIT STARTING FROM S/N SEE REFERENCE ON
WEB PARTS
[K1] 9100001169 1 HARDWARE WHEEL D.254X80 KIT
