PARTS LIST
01/2015 RA40 - 9100000394 93
FRONT WHEEL SYSTEM
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
1# 1467636000 1 BEARING TAPER ROLLER 32006 SIP
2# 9100001349 1 NUT RING M15X1 KMA2 LIGHT S. 10 PCS SET
3# 9100001734 1 SUPPORT BALL BEARING SIP
4# 1467639000 1 BEARING TAPER ROLLER 32004X
5 9100001160 1 SCREW 10X16 M8 ISO7379 12.9 10 PCS SET
6# 9100001646 1 SUPPORT FRONT WHEEL ASSEMBLED SIP
7# 9100002334 1 WHEEL D.200X76 GREY-BLACK SIP
8 9100001101 1 PIN WHEEL SIP
Revised 07/2017
