PARTS LIST
01/2015 RA40 - 9100000394 95
STEERING COLUMN SYSTEM
Revised 07/2017
KIT ITEM REF. NO. QTY DESCRIPTION NOTE
K1 1 1 SCREW M5X50 UNI5931 5X50
K1 2 1 NUT SELF L. M5 UNI7474
K1 4 2 SPACER D.5X8X11.5
5# 9100001345 1 RING D 17 UNI7435 10 PCS SET
K1 6 2 WASHER 5X15X1.5 UNI6593
7 1466146000 1 kEY 5X5X25 UNI6604A SIP
8 1466319000 1 JOINT UNIVERSAL D.17 SIP
9# 9100001350 1 SCREW GRUB M5X10 UNI5929 10 PCS SET
10 9100001085 2 BEARING FLANGE IGLIDUR GFM-4044-14 SIP
11 9100001087 1 RING D.40 UNI7436 SIP
12# 9100001450 1 TUBE STEERING KIT
13 9100001093 1 BEARING NEEDLE ROLLER NK 17/20 SIP UNTIL S/N 3510163104804
13# 9100001449 1 HARDWARE STEERING SUPPORT KIT
13# 9100002416 1 BEARING BALL 6203 2RS 2 PCS SET STARTING FROM S/N 3510163104805
14 9100001107 1 SHAFT STEERING UPPER SIP
15 9100001109 1 SUPPORT STEERING COLUMN SIP
16 9100001110 1 SHAFT STEERING LOWER SIP
17 9100001125 1 PINION Z25 SIP
[K1] 9100001170 1 HARDWARE STEERING TUBE KIT
