Clarke Vantage 17 E - Page 10

ENGLISH INSTRUCTIONS FOR USE
8 VANTAGE 17 E - 9099653000
31
32
42
36
41
34
46
33 35
37
43
38
39
40
44
45
P100649
MACHINE STRUCTURE (Continues)
31. Recovery water tank cover (open)
32. Recovery tank cover gasket
33. Front brush/pad-holder support
34. Recovery tank compartment
35. Solution tank ller neck
36. Vacuum grid with automatic shut-off oat
37. Safety rod for open cover
38. Vacuum system motor
39. Brush/pad-holder motor
40. Machine straight forward movement adjusting handwheel
41. Machine forward speed adjusting handwheel
42. Brush
43. Pad-holder
44. Pad
45. Brush rotation direction
46. Lifted squeegee
