ENGLISH INSTRUCTIONS FOR USE
10 VANTAGE 17 E - 9099653000
TECHNICAL DATA
Model Vantage 17 E
Solution tank capacity 8.2 US gal (31 liters)
Recovery tank capacity 7.9 US gal (30 liters)
Machine length 43.9 in (1,115 mm)
Machine width with squeegee 28.3 in (720 mm)
Machine width without squeegee 22.4 in (570 mm)
Machine height with adjustable handlebar 41.3 in (1,050 mm)
Counterweight (optional) 72.7 lb (33 kg)
Minimum turning radius 29.5 in (750 mm)
Cleaning width 17 in (430 mm)
Wheel diameter 9.8 in (250 mm)
Wheel pressure on the oor 188 psi (1.3 N/mm
2
)
Brush/pad diameter 17 in (430 - 432 mm)
Brush/pad pressure with full tank and lowered squeegee 106 lb (48 kg)
Min/max solution ow 0.1 / 0.42 gpm (0.4 / 1.6 liters/min)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 74 dB(A) ± 3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 91 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 98.4 in/s
2
(< 2.5 m/s
2
)
Maximum gradient when working 2%
Protection class (IP) X4
Protection class (electric) I
Vacuum system motor power 0.73 hp (550 W)
Vacuuming 0.0127 MPa (1,300 mmH
2
O)
Brush/pad motor power 0.73 hp (550 W)
Brush/pad-holder motor speed 180 rpm
Electrical system voltage 115 V - 60 Hz
Total absorbed power 10 A (1.1 kW)
Weight with empty tanks 143 lb (65 kg)
Gross vehicle weight (GVW) 278 lb (126 kg)
Shipping weight 216 lb (98 kg)
