HANDLEBAR AND CONTROL PANEL
51. Brush enabling push-buttons
52. Brush/pad-holder activation switch
53. Vacuum system activation switch
54. Solution ow push-button Press to reach the desired
quantity, as shown by LEDs (55).
55. Solution ow quantity LED indicators:
– 1 LED on: Minimum solution ow.
– 2 LEDs on: Medium solution ow.
– 3 LEDs on: Maximum solution ow.
– LEDs off: Closed solution ow.
2 3
51 51
52 53 55 54
P100650
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
– Brushes/pads of different materials
– Counterweight
For further information concerning the optional accessories, contact an authorised Retailer.
