PARTSLIST
07/2012 9098653000 - VANTAGE 17 E 71
SOLUTIONSYSTEM
KIT ITEM REF.NO. QTY DESCRIPTION
K1 1 1 EPDM CAP FOR
K1 2 5 WASHER, FLAT XL
K1 3 2 SCREW, PAN PHIL M5X10 LOCTITE
K1 4 1 CLAMP, CABLE Ø12.7
K1 5 5 SCREW, PAN PHIL M6X12
K1 6 1 SCREW, PAN PHIL M5X12
K1 7 1 TIE, CABLE 4,8X430
8 909 6380 000 1 CLAMP KIT
K1 9 1 WASHER, FLAT XL 5,5X15
K1 10
1 FLAT TIE HOLDER
K1 11 1 SCREW, HEX THD TO HD M5X16
12 9097383000 1 ELBOW Ø20
K1 13 1 THREAD ROLLING SCR 5x16
14 9098443000 1 ELBOW Ø20
15 9098446000 1 SOLUTION HOSE 600 mm
16 9098466000 1 MOTOR COVER
K1 17 3 TIE, CABLE 4,8X200
K1 18 1 CLAMP, HOSE 14/32-52
19 9099033000 1 BLUE FRESH WATER TANK
20 9099195000 1 FRONT ADJUSTABLE SUPPORT
K1 21 3 AVIBRATION DAMPING EI TYPE
K1 22 1 CLAMP, HOSE D.18
23 909 5564 000 1 ACOUSTIC INSULATION PIPE
24 909 5565 000 1 ACOUSTIC INSULATION PIPE
25 909 5579 000 1 VACUUM MOTOR HOSE
26 909 5979 000 1 VACUUM MOTOR 550W 115V CPL (M2)
27 909 5719 000 2 BRUSHES
28 909 6304 000 1 HOOK FOR BRUSH
K1 29 1 SPACER 5.5X8X3
30 9098444000 1 POWER SUPPLIE CABLE SUPPORT
31 9098802000 1 FILTER LEVEL WATER HOSE
[K1] 9099763000 1 HARDWARE SOLUTION TANK KIT
