Clarke Vantage 17 E - Page 75

PARTSLIST
07/2012 9098653000 - VANTAGE 17 E 73
FILTERANDWHEELSSYSTEM
KIT ITEM REF.NO. QTY DESCRIPTION
K4 1 2 SCREW,PAN PHIL THD FORM
K4 2 1 SCREW, HEX THD TO HD M5X10
K4 3 2 SCREW, HEX THD TO HD M5X12
K4 4 2 NUT, HEX NYL LOC THIN M5
K4 5 2 WASHER, FLAT 5,3X10
6 9097626000 1 VALVE ELBOW KIT
K1 7 909 5215 000 1 NET & GASKET WATER FILTER
K1 8 1 FILTER SOLUTION
9 9099778000 1 HOSE SOLUTION FILTER KIT
K4 10 1 WASHER, SPLIT LOCK D.5
11 9099200000 1 RUBBER ADHESIVE SPACER
12 9099248000 1 SOLENOID VALVE 110-115V (EV1)
13 9099179000 1 FILTER - SOLENOID VALVE SUPPORT
14 9096916000 1 FILTER SOLUTION TANK
K2 15 1 NUT, HEX NYL LOC THIN M10
K2 16 1 PIVOT WHEEL 50X24
K2 17 1 MACHINE SUPPORTING ROAD
K2 18 1 MACHINE SUPPORTING ROAD
K2 19 1 PIN, SPRING 3X20
K2 20 1 PLUGER INDEXING
K2 21 1 WASHER, FLAT 10X16X2.0
K4 22 2 WASHER, FLAT XL
K4 23 2 WASHER, SPLIT LOCK D.6
K4 24 2 SCREW, HEX THD TO HD M6X14
K3 25 2 SCREW, FLAT SOCKET HEAD
K3 26 2 BUSHING
27 9099410000 2 WHEEL D250X50 GREY RING BLACK BODY
K3 28 2 SPACER 17X21X10.5
K3 29 2 SHAFT RING D 17
K3 30 4 WASHER, FLAT 17X30
K3 31 1 WHEELS SHAFT
32* 909 6226 000 1 RUBBERSHOCKABSORBERKIT
K1 9097404000 1 FILTER SOLUTION
K2 9099705000 1 WHEEL KIT
[K3] 9099765000 1 HARDWARE WHEELS SHAFT KIT
[K4] 9099766000 1 HARDWARE FILTER AND SUPPORT KIT
PER WEB: mettere sul 9099705000 una nota con disponibile i seguenti ricambi no a esaurimento scorte
K2 16 909 5560 000 1 PIVOT WHEEL 50X24 RUOTA GIREVOLE 50X24
K2 17 909 5649 000 1 MACHINE SUPPORTING ROAD SUPPORTO ASTA SOSTEGNO MACCHINA
K2 18 909 5658 000 1 MACHINE SUPPORTING ROAD ASTA SOSTEGNO MACCHINA
K2 19 909 6441 000 1 PIN, SPRING 3X20 SPINA ELASTICA 3X20
K2 20 9099135000 1 PLUGER INDEXING PISTONCINO A MOLLA
