PARTSLIST
07/2012 9098653000 - VANTAGE 17 E 75
RECOVERYSYSTEM
KIT ITEM REF.NO. QTY DESCRIPTION
K2 1 2 WASHER, FLAT XL SS
2
145 0543 000 2 CLAMP
3
909 6289 000 1 SUCTION HOSE
4 909 6273 000
1 BLUE TANK COVER
K2 5 1 GASKET FLOAT SUPPORT
K2 6 2 NUT DRIVIN 6X6 SS
K2 7 2 SCREW, BUTTON SOC M6X20
8
9099692000 1 HOSE DRAIN KIT
9 909 6272 000
1 BLUE RECOVERY TANK
K2 10
1 SUPPORT FLOAT SYSTEM
11
L08812373 1 FLOATING BALL
12
L08812259 2 FLOAT CAGE
13
909 5065 000 1 FILTERANTIFOAMING
K1 14 1 CAP BLACK
K1 15 3 SCREW, FLT PHIL THD FORM M4,2 X 50
16 909 6268 000
1 GASKET
K1 17 1 PLATE FIXING LEVER
K1 18 1 LOCK SPING COVER LEVER
K1 19 1 FIXING COVER LEVER
K1 9099776000 1 LEVER FIXING COVER KIT
K2
9099767000 1 SUPPORT FLOAT KIT
