PARTSLIST
07/2012 9098653000 - VANTAGE 17 E 77
HANDLESYSTEM
KIT ITEM REF.NO. QTY DESCRIPTION
K2 1 4 SCREW 4.2X16 THD FORM
K1 2 2 NUT M8
K1 3 2 CAP D. 9.5
K1 4 2 SWITCH LEVER
K1 5 2 SPRING
6 909 6488 000 1 HANDLE BAR PE
K1 7 2 WASHER FLAT 8X17
8 909 6768 000 1 HARNESS HANDLE CABLE
9 909 6774 000 1 PIN HANDLE BAR
K1 10 2 SWITCH HOUSING
K1 11 4 SWITCH
12 9099144000 1 HARNESS DASHBOARD
13 9099199000 1 CONTROL PANEL PLATE
K2 14 5 SCREW M3X8 UNI7688
15 9099381000 1 DECAL CA D5 BLUE CONTROL PANEL
16 9099053000 1 TWO-COLOURED LED BOARD (EBLED)
17 9099107000 1 SINGLE-POLE MOMENTARY SWICTH (SW3)
18 L08603154 1 CAP PROTECTION
19 909 5584 000 1 SWITCH (SW2)
20 909 5584 000 1 SWITCH (SW1)
K1 11053A 2 SWITCH ASSEMBLY KIT (SW4,5)
K2 9099780000 1 HARDWARE HANDLE BAR SYSTEM KIT
