PARTSLIST
07/2012 9098653000 - VANTAGE 17 E 81
BRUSHSYSTEM
KIT ITEM REF.NO. QTY DESCRIPTION
1 909 5964 000 1 KNOB M8
K1 2 1 WASHER, FLAT XL
K1 3 6 WASHER, FLAT XL SS
4 9099356000 1 BRACKET SUPPORT BRUSH
5 145 9774 000 1 KEY 5X5X20
K1 6 1 SPACER 9X15X13
K1 7 1 CLAMP, HOSE 09/12-22
K1 8 1 SCREW, HEX THD TO HD M8X25
K1 9 1 SCREW, HEX THD TO HD M8X30
K1 10 2 NUT, HEX NYL LOC THIN M8
K1 11 2 WASHER, FLAT XL 9X24 COPPER
K1 12 1 NUT, HEX NYL LOC THIN M8 SS
K1 13 4 SCREW, HEX THD TO HD M6X25 SS
K1 14 1 WASHER, FLAT XL SS
K1 15 3 SCREW, PAN HD THD FORM
16 L08812589 1 HOLDER POLYG.W/FLANGE KIT
17 L08812480 1 HUB BRUSH
18 9099385000 1 REDUCTION GEARMOTOR 550W 115V (M1)
19 9099055000 1 REDUCTION GEAR
20 909 5482 000 1 ELECTRIC MOTOR 550W 115V
21 909 5481 000 1 CAPACITOR 450V 40ΜF
21 909 5106 000 1 CAPACITOR 400V 65ΜF
K1 22 1 SPACER WITH HOLE
K1 23 1 SPACER
24 9099779000 1 HOSE BRUSH DECK KIT
25 9099093000 1 BRUSH DECK
26 9099190000 1 SOLUTION PIPE SUPPORT COVER
K1 27 3 WASHER, FLAT 17x30
K1 28 1 WASHER 15
29 L08812204 1 ROLLER BUMPER
K1 30 1 CAP. BLACK
K1 31 1 WASHER 5X15 UNI6593
32 9099771000 1 ADJUSTABLE DECK KIT
K1 33 1 SCREW, HEX M5X16
K1 34 1 SCREW, HEX M8X90
35 9098465000 1 KNOB
K1 36 1 SCREW, HEX THD TO HD M8X85
K1 37 1 NUT, HEX NYL LOC THIN M10
K1 38 1 BUSHING
K1 39 1 SCREW, SOC HD M12X55
40 33003977 1 SCREW, HEX THD TO HD M6x30
41 145 9171 000 1 WASHER, FLAT XL
K1 42 3 SCREW M6X20 UNI5931 SS
K1 43 3 WASHER NORD LOCK M6
44 9097184000 1 VIBRATION DAMPING EI TYPE
45 9099149000 1 CABLE BRUSH MOTOR
[K1] 9099772000 1 HARDWARE BRUSH SYSTEM KIT
