PARTSLIST
07/2012 9098653000 - VANTAGE 17 E 83
WIRINGSYSTEM
ITEM REF.NO. QTY DESCRIPTION
1 909 6656 000 1 CLIP
2 909 5648 000 3 CLAMP CABLE PG 13.5
3 909 5862 000 1 CORD, POWER
4 909 6657 000 1 RING NUT
5 9098463000 1 CLIP
K2 6 1 ELECTRICAL BOX COVER
K2 7 1 ELECTRONIC BOX
8 9099090000 2 POWER SUPPLY WIRE
9 9099148000 1 US ELECTRONIC CARD US (EB1)
10 9099150000 1 US HARNESS VACUUM MOTOR US
11 9099151000 1 US HARNESS SOLENOID VALVE US
12 9099357000 1 DOUBLE-POLE SWITCH
K1 13 4 SCREW,PAN PHIL THD FORM
K1 14 5 SCREW,PAN PHIL THD FORM
K1
15
2 SCREW, PAN PHIL M5x16
K1
16
3 WASHER, FLAT XL 5,5x15
17 9099030000 1 RUBBER SPACER 6MM
18 909 5791 000 1 SUPPLY CORD EXTENTION
[K1] 9099774000 1 BOX ELECTRIC KIT
