24 P2077SB/EN 2011-09 77f_Schraubmodul-en.fm, 06.09.2011
Tightening module TSE/TUSE
6
6.1 Description
The tightening module TSE/TUSE controls the DGD-IS.
The servo amplifier (output section) and the measuring section (measuring board) are integrated in the
tightening module.
Both circuit boards are linked to the connections via cables and plug connectors.
6.2 General technical data
6.2.1 Power loss
Low-loss components generate minimal heat.
Extremely good heat dissipation. Overall housing serves as a cooling element.
6.2.2 Power supply 380 VDC
Intermediate power circuit (380 VDC) and logic power (24 VDC) are supplied separately by the
PDB-CPS…. In the event of an emergency stop the intermediate power circuit is switched off separately
by the PDB-CPS…. The logic section remains connected to the power.
Performance data DGD-IS different
Features Data
Weight:
TSE
TUSE
1480 g
1500 g
Protection category – is attained
when all connectors are plugged in
and the service panel is closed.
IP54
Cooling type Convection (self-cooling)
Service life, operating 40,000 h
Usability period if stored 100,000 h (approx. 11 years)
Acceleration of each axis max. 100 m/s²
Standby 9 A
Operation max. 40 W
WARNING!
High temperature –
the tightening module TSE/TUSE may heat up and cause burns during removal
(max. temperature 70 °C). Wear gloves.
Features Data
1B(U)TSE… 2B(U)TSE… 3B(U)TSE… 4B(U)TSE…
Supply voltage VDC 380 ±10 %
Rated supply current A 0.5 1 2 2
Peak supply current A 6 15 15 15
