17i_Kabel en.fm, 06.09.2011 P2077SB/EN 2011-09 53
Cable
13
13 Cable
13.1 HighFlex Quality, suitable for cable ducts
13.1.1 System cable, type C
Thermal properties
Ambient temperature °C -20…+80
Flammability Flame-retardant and self-extinguishing in accordance with
EN 50265-2-1, IEC 60332-1 and UL1581
Chemical properties of the coating
Coating material PUR, low-adhesion, resistant to hydrolysis and microbes,
UV-resistant, abrasion-resistant, tear-resistant, cut-resistant,
notch-resistant
Oil resistance Oil-resistant in accordance with DIN VDE 0472, part 803
ASTM oil 1 to 3 and HD 505.2.1
Resistance to hydrolysis In accordance with VDE 0283, part 10
Color RAL 2003 matt
Mechanical properties
Diameter mm approx. 13,8
Bending radii:
Single bends
Multiple bends
mm
30 min.
95 mm min. flexing action
130 min alternate bending
Torsional length
(±180 ° around separate
central axis)
mm 500 min.
Max. acceleration m/s² 100
Use Nutrunner control unit – DGD-IS
Order No. 961109-××× (…-××× = cable length in dm)
