Gearing
9
9 Gearing
10 Motor
10.1 Technical data
Size
Gearing
…B…
Code Part no. Ratio
1 1B012A 927346 5.7273
1B035A 927344 15.1364
1B060A 927345 25.7727
2 2B110A 935548 12.3595
2B200A 935549 21.9231
3 3B300A 935590 18.7500
4 4B360A 929541 26.3118
4B500A 935780 33.4219
4B660A 935781 48.9345
Features Data
Code 1BT 1BUT 2BT 2BUT 3/4BT 3/4BUT
Part no. 935560 935563 935561 935564 935562 935565
Speed, maximum
RPM
11000 11000 8500
Operating mode according to
VDE 0530
S 1 S 1 S 1
Enclosure type according to
DIN 40050
IP54 IP54 IP54
Sense of rotation Reversible Reversible Reversible
Design B14 B14 B14
Connection type Plug connector Plug connector Plug connector
Mass moment of inertia
kgm² × 10
-3
0.017 0.06 0.25
Rated torque
Nm
0.55 1.60 3
Permanent torque, maximum
at a stop
Nm
0.61 1.8 4
Peak torque
Nm
2.8 10.5 18.3
Speed change per torque
rpm / Ncm
1)
12.2 1.9 0.34
Mechanical time constants
ms
2.1 1.3 1.1
Friction torque
Nm
0.03 0.07 0.15
Rotor weight
kg
0.36 0.79 1.54
Motor weight
kg
1.6 3.1 6.5
Ball bearing
A/B side
6000/608 6200/6200 6202/6201
