Cable
13
13.2 Super Highflex, suitable for robots
13.2.1 System cable, type A
13.2.2 Jumper cable, type F
Thermal properties
Ambient temperature °C -20…+90
Flammability Flame-retardant and self-extinguishing in accordance with
EN 50265-2-1, IEC 60332-1 and UL1581
Chemical properties of the coating
Coating material PUR, low-adhesion, resistant to hydrolysis and microbes,
UV-resistant, abrasion-resistant, tear-resistant, cut-resistant,
notch-resistant
Oil resistance Oil-resistant in accordance with DIN VDE 0472, part 803
ASTM oil 1 to 3 and HD 505.2.1
Resistance to hydrolysis In accordance with VDE 0283, part 10
Color Orange RAL 2003 matt
Mechanical properties
Diameter mm approx. 14
Bending radii:
Single bends
Multiple bends
mm
30 min.
60 mm min. flexing action
43 min alternate bending
Torsional length
(±180 ° around separate
central axis)
mm 500 min.
Max. acceleration m/s² 100
Use Intermediate plug position – DGD-IS
Order No. 961103-××× (…-××× = cable length in dm)
Use DGD-IS – DGD-IS
Order No. 961395-××× (…-××× = cable length in dm)
