30 P2077SB/EN 2011-09 77g_Komponenten-en.fm, 06.09.2011
Attachment
7
7.2.1 Pin configuration of offset attachment
Type: 12-pin circular connector Lumberg SGR 120, Binder series 680 no. 09-0331-90-12
with locking connector in accordance with DIN 45 321
7.3 Angle head attachment
Pin Color Signal Description
A–– nc
B Brown – nc
C green TQ Torque output
D Yellow 0 VA 0 V torque reference connection
E gray 0 V 0 V supply
F Pink +12 V Supply
G Blue – nc
H Red RxD+ interface
Y Black RxD- interface
K Violet CAL Input calibration voltage
L Gray / pink TxD- interface
M Red / blue TxD+ interface
Housing PE Shield connection
Code Part no. Torque
Calibration
Ratio
i
Permissible load
on output shaft
Lateral force
on square
1)
TQ
Nm
Pres-
sure
1)
N
1) During continuous operation for long periods, multiply the specified values by 0.3
Ten-
sion
1)
N N
1WM1B 934367PT 35
1.0667 53 1700 3400 31001WM2B 934368PT 60
1WM3B
2)
2) On request
12
2WM1B 934357PT 110
1.0625
110
1850 3900 4200
2WM3B 934374PT 200 200
3WM2B 2) 300 1.0385 300 3800 4800 5100
4WM2B 2) 500
1.0370 660 1200 6500 5900
4WM3B 2) 660
a00334_1.eps
Helix-toothed
bevel wheels
Cap nut
Crown gearing
Range
torque measurement
