48 P2077SB/EN 2011-09 77h_PowerDistributionBox-en.fm, 06.09.2011
Power distribution box PDB-CPS…
11
Dimensions / drilling pattern
Transformer A
mm (")
B
mm (")
C
mm (")
D
mm (")
E
mm (")
CP3-3750-JH3
387 (15.25) 314 (12.38) 229 (9.00) 286 (11.25)) 454 (8.50))
CP3-6750-JH6
CP3-9750-JH9 406 (16.00) 486 (19.12) 222 (8.75) 216 (8.50) 216 (17.88)
NOTE
➔ When installing, keep a distance of 25.4 mm from voltage-conducting components.
