100
Figure 99
Step 1
Position Carrier Cover above Inner Carrier Shell and
slide top of Carrier Cover over top edge of Inner
Carrier Shell.
Smooth Carrier Cover down into the seat until the
bottom contacts the bottom of the Inner Carrier Shell,
then pull bottom elastic edge of the Carrier Cover down
and over the bottom edge to secure it around bottom
edge of Inner Carrier Shell.
Attach side tab on each side of Carrier Cover by
tucking tab under edge of Inner Carrier Shell, as shown
in Figure 99.
Check that Carrier Cover is in position with the
Shoulder Harness Slot openings aligned between the
Carrier Cover and the Inner Carrier Shell.
TO INSTALL CARRIER COVER
• Unfasten side tab on each side by sliding tabs down
and out from under the edge of the Inner Shell, as
shown in Figure 98.
• Pull up on top of Carrier Cover to complete removal
of Carrier Cover.
Figure 98
To Next Page
