Figure 96
Figure 97
Step 8
Remove Shoulder Harness Straps from Inner Carrier
Shell.
For each Shoulder Harness Strap:
• Push Buckle Tongue down through hip strap opening
in Carrier Cover and Inner Carrier Shell, as shown in
Figure 96.
• Position Chest Clip so that end of Chest Clip is
aligned with the hip strap opening, and push Chest
Clip down through hip strap opening in Carrier
Cover and Inner Carrier Shell, as shown in
Figure 97.
• Position hand between Inner and Outer Carrier
Shell and pull remaining Shoulder Harness Strap
length down through the hip strap opening.
Step 9
Remove Carrier Cover:
• Release bottom edge of Carrier Cover from Inner
Carrier Shell by sliding Cover up and over the bottom
edge.
