98
Step 6
Pull Harness Adjuster Strap out of Inner Carrier Shell as
shown in Figure 93.
DO NOT remove Harness Adjuster Strap from Outer
Carrier Shell.
Step 7
Remove Crotch Strap and Buckle from Buckle Pad
by pressing down on top of Buckle to push it down
and out of Buckle Pad as shown in Figure 94.
Lift Inner Carrier Shell with one hand and use other
hand to pull Buckle and Crotch Strap out of Inner
Carrier Shell as shown in Figure 95.
Figure 94
Figure 95
Figure 93
