97
Figure 91
Step 3
Turn Carrier over and remove loop at end of each
Shoulder Harness Strap from Metal Harness Plate by
sliding Strap out through slot in Metal Harness Plate as
shown in Figure 91.
From front of Carrier, pull Shoulder Harness Straps out
of Carrier Seat Back.
(If present) Remove the Newborn Support System. See
“Support Cushion Removal/Installation” and “Support
Headrest Removal/Installation” sections on page 27.
Step 4
Turn Carrier over and locate Inner Shell Release Tabs.
Press each Inner Shell Release Tab away from the center
of the Carrier, as shown in Figure 92 and press down.
NOTE: It may be easier to place Carrier on its side and
release Shell Release Tab that is on top (with one hand),
while pulling Inner Shell away from Outer Shell (with
the other hand). Then, flip the Carrier over to the
opposite side and repeat.
Step 5
Turn Carrier on side and pull Inner Carrier Shell
away from Outer Carrier Shell.
Figure 92
