59
WARNING
• NEVER extend the Load Leg further than needed to turn the Load
Leg Indicator from red to green.
• Only use Load Leg when the Indicator is green.
St e p 11
Adjust recline:
• Pull and hold Recline Sled Adjustment Handle
and rotate Recline Sled, as shown on Figure 49,
to the position that places the Recline Bubble
between the appropriate lines on the Recline
Indicator appropriate for the child’s weight.
Check that Recline Sled is locked into the
adjustment position and not between adjustment
positions.
NOTE: Vehicle MUST be parked on level surface
when checking or adjusting the recline position.
Figure 49
11-22 lb
22-35 lb
4-11 lb
10-
15.9 kg
5-10 kg
1.8-5 kg
Adjust recline so bubble is between
2 lines designated for child's weight
Réglez l’inclinaison de manière à ce que la bulle soit
entre les deux lignes prévues pour le poids de l’enfant
