Clek Liing - Page 63

63
Step 4
Store LATCH Connectors as shown in Figure 54:
• Press and hold LATCH Adjustment Button (1).
• Grasp the end of the LATCH Connector located
on the same side of the Base and push to slide
Connector back into Base (2).
• Repeat on opposite side for other LATCH Connector.
Step 5
Store Load Leg:
• Turn Base over and rotate Load Leg into Load Leg
Storage on bottom of Base. Press down on Load Leg
to lock in place as shown in Figure 55.
Step 6
Remove Base from vehicle.
Figure 54
2
7
6
5
4
3
2
1
1
Figure 55
