4.4.3 Dust collector
See separate owner’s manual.
4.5 Requirements for setting up a cabinet
Basic requirements: See yellow cover sheet
Space requirements:
BNP 65
BNP 75
BNP 220
BNP 85
MBX 1500
A =
1054 mm
2 x A
1420 mm
2 x A mm
D =
1200 mm
B =
910 mm
910 mm
1000 mm
1000mm
D1 =
480 mm
B1 =
1460 mm
1460 mm
1550 mm
1550 mm
F =
2090mm
C =
1970 mm
1970 mm
2105 mm
2105 mm
Picture 3a: Space requirementsBNP-65, 75, 220 & 85
with Cyclon 600 CFM (on the rear wall of the cabinet) and MBX dust collector
Picture 3b: Required space for BNP-65 & 220 with stand alone cyclone and MBX-filter
