Seite 38 von 38
Port 400 x 400 mm including
mounting
Tumble 4,5 l complete with E-
motor 230V (door mounting
possible))
Openings in door
Setting electrical
connections
Tumble 30 l complete with E-
Motor 230V (door mounting
possible)
Openings in door
Setting electrical
connections
Tool for window installation
*1) not possible
9.8.1 Further options
Re-fittings possibles by customer
Reinforcements for loadings till 5000 N
Reinforcements for loadings till 20000 N
Oscillator horizontal , vertical)
9 Wiring diagram
See control box
10 Disposal
Unless a return or disposal agreement has been made, recycle the dismantled components:
- Scrap metals.
- Send plastic elements for recycling.
- Dispose of remaining components sorted according to material properties.
ATTENTION!
Environmental damage through incorrect disposal!
Electronic scrap, electronic components, lubricants and other auxiliary materials are
subject to hazardous waste treatment and may only be disposed of by approved specialist
companies!
The local authority or special waste disposal companies provide information on environmentally friendly disposal.
