Clemco BNP Series User Manual

Seite 34 von 38
(3)
Nozzle (long) 6“, 11 mm option
11929Z
(3)
Nozzle (long) 9“, 8 mm option
11924Z
(3)
Nozzle (long) 9“, 9,5 mm option
11925Z
(3)
Nozzle (long) 9“, 11 mm option
11926Z
(4)
O-ring
12031Z
(5)
Gun housing
11802Z
(6)
Nut
11918Z
(7)
Rubber bushing
12097Z
(8)
Orifice no.: 4 (3,2 mm) for blast nozzle 6 mm
12342Z
Orifice no.: 5 (4,0 mm) for blast nozzle 8 mm
12343Z
Orifice no.: 6 (4,8 mm) for blast nozzle 9,5 mm
12344Z
Orifice no.: 7 (5,6 mm) for blast nozzle 11 mm
12345Z
Orifice no.: 8 for blast nozzle 11 mm (special case)
12346Z
(9)
Union 0219-030
11723Z
(10)
Fitting 3/8“ 0219-034 (brass)
11724Z
(10)
Fitting autom. gun (stainless steel)
100756
(11)
Air hose 1/2“ per m
12472Z
(12)
Blast hose PU 1/2“ per m
12476Z
Clamp collar for long nozzles
*with thread for fixing on rack; O= without ; M=centric ; R= right; L=left
