Service Manual
2 - 2
Disassembly steps
From the list below choose the component that you want to disassemble, then follow the steps listed
and go to the appropriate page for detailed instruction.
Steps to remove the CD device assembly:
Remove the battery p 2-5
Remove the keyboard p 2-6
Remove the heat sink p 2-9
Remove the CD device assembly p 2-8
Steps to remove the CPU:
Remove the battery p 2-5
Remove the keyboard p 2-6
Remove the heat sink p 2-9
Remove the CPU p 2-10
Steps to remove the FDD assembly:
Remove the battery p 2-5
Remove the keyboard p 2-6
Remove the HDD assembly p 2-7
Separate the notebook base in two p 2-12
Remove the FDD assembly from the mainboard p 2-15
Remember to
wear an anti-
static wrist strap
and remove all
power sources
when working on
the computer.
Note
To Next Page
