Clevo 2700T User Manual

Disassembly
2 - 7
figure 2-5
1
2
3
4
figure 2-6
Remove the HDD assembly
1. Remove 3 screws (D) holding the HDD assembly in place (figure 2-5).
2. Lift the HDD assembly out of the case using the HDD tab (figure 2-6).
1 Philips screw-
driver
3 screws


1) HDD assem-
bly
2) HDD tab
3) HDD connec-
tor
4) HDD socket
For information
on removing the
HDD from the
HDD assembly
go to Appendix
A.
Note
D
D
D
