Clevo 2700T - The LCD Panel

Service Manual
2 - 18
The LCD Panel
Remove the LCD panel frame
1. Remove the rubber stoppers in positions D and J (figure 2-20).
2. Remove the screws (D, J) (figure2-20).
3. Run your finger around the middle of the frame and separate
the frame from the back (figure 2-21).
figure 2-21
2
3
figure 2-20
1

1 Philips
screwdriver
5 Screws

1) Top half of
notebook
computer
2) LCD panel in
back
3) LCD panel
frame
J J
J
D
D
