Clevo 2700T - Remove the Mainboard and Tray from the Bottom Case

Service Manual
2 - 16
Remove the mainboard and tray from the bottom case
1. Remove screws (F, H) and hex nut (Q).
2. Lift the mainboard up from the battery side and pull it out of the case.
figure 2-18

1 Philips screw-
driver
1 Hex socket
wrench
2 Screws
1 Hex nut
Q
F
H
