Clevo 2700T User Manual

Service Manual
2 - 20
4. Lift the inverter board and disconnect the in-
verter cable and the LCD to inverter cable (figure
2-23).
5. Lift the LCD screen and bracket out of the case
and place it atop the keyboard (figure 2-24).
6. Disconnect the LCD cable.
3
4
figure 2-24
5
5
1
figure 2-23
2

1) Inverter
cable
2) LCD to in-
verter cable
3) LCD cable
4) LCD cable
connector
5) LCD bracket
