Clevo P170SM - External Locator - Top View

Introduction
1 - 4 External Locator - Top View with LCD Panel Open
1.Introduction
External Locator - Top View with LCD Panel Open
Figure 1
Top View
1. Built-In PC
Camera
2. PC Camera LED
3. Built-In
Microphone
4. LCD
5. Speakers
6. LED Indicators
7. Power Button
8. Illuminated
Keyboard
9. TouchPad and
Buttons
10.Fingerprint
Reader (Optional)
3
2
1
8
9
7
6
5
4
5
10
Note tha t the Touchpad a nd
Buttons has a valid operation-
al area ind icated w ithin the
red dotted lines above.
