Clevo P170SM - External Locator - Left Side and Rear Views

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
Figure 4
Left Side View
1. Mini-IEEE 1394a
Port
2. RJ-45 LAN Jack
3. USB 3.0 Port /
USB Charge
4. USB 3.0 Port
5. Combined eSATA/
Powered USB 3.0
Port
6. Multi-in-1 Card
Reader
1
2
4
5
6
3
Figure 5
Rear View
1. Vent/Fan Intake
2. Display Port
3. HDMI-Out Port
4. Mini Display Port
5. DC-In Jack
6. Security Lock Slot
2
3
5
1
4
1
6
