ClimaCool UCW 30 - Electrical Data UCH

53
®
www.climacoolcorp.com
Electrical Data UCH
Rated Min.Cir. MaxFuse Rec. Discon. Rated Min.Cir. Locked MaxBreaker Rec.
Load Amps Size Fuse Switch Load Amps Rotor Size Fuse
Amps
1
(MCA)
2
(MOP)
3, 4
Size
4,5
Size
6
Amps
1
(MCA)
2
(LRA)
7
(MOP)
3
Size
4, 5
UCH030AHASAXB0S
208-230/3/60 113 127 175 150 175 56.4 70.5 425 125 N/A
UCH030AFASAXB0S
460/3/60 51 57 80 70 80 25.5 31.9 173 50 40
UCH030ANASAXB0s
575/3/60 41 46 60 60 70 20.4 25.5 128 45 35
UCH050AHASAXB0S
208-230/3/60 189 213 300 250 300 94.7 118.4 605 200 N/A
UCH050AFASAXB0s
460/3/60 86 96 125 110 150 42.8 53.5 272 90 70
UCH050ANASAXB0s
575/3/60 69 77 110 90 110 34.3 42.8 238 70 60
UCH070AHASAXB0s
208-230/3/60 249 280 400 325 400 124.3 155.4 599 250 N/A
UCH070AFASAXB0s
460/3/60 112 126 175 150 175 56.2 70.3 310 125 N/A
UCH070ANASAXB0s
575/3/60 90 101 125 125 150 45.0 56.2 239 100 70
UCH085AHASAXB0s
208-230/3/60 317 357 500 400 500 158.5 198.1 732 350 N/A
UCH085AFASAXB0s
460/3/60 144 162 225 200 225 71.7 89.6 368 150 N/A
UCH085ANASAXB0s
575/3/60
115 129 175 150 175 57.3 71.7 292 125 N/A
1.
RLA - Rated Load Amps are calculated as per UL1995.
2.
3.
4.
5.
6.
7.
LRA - Locked Rotor Amps are instantaneous starting amperage per compressor.
8.
Module internal wiring is per NEC.
9.
Power Wiring - per Module
Model
Type
Model #
Voltage
UCH050 UCH070
UCH085
Internal Wiring - per Compressor
UCH030
575V / 60 Hz: Min. 518V Max. 632V
MOP Device or Recommended Fusing Device for Module Power Wiring supplied by others. These are recommended values for electrical power protection of modules selected. Disconnect Switch for Module Power Wiring supplied by others. These are recommended values for electrical power protection of modules selected.
NOTES:
MCA - Minimum Circuit Ampacity is: 125% of the RLA of the largest compressor motor plus 100% of the RLA of all other concurrent motors and/or electrical loads. MOP - Maximum Overcurrent Protected device amp size is rounded down from: 225% of the RLA of the largest compressor motor plus 100% of the RLA of all other concurrent electrical loads.
Recommended Dual Element Fuse Sizing: Rounded up from 150% of the RLA of the largest compressor motor plus 100% of the RLA of all other concurrent electrical loads.
Voltage Tolerance Range:
208-230V / 60 Hz: Min. 187V Max. 253V
460V / 60 Hz: Min. 414V Max. 506V
