Troubleshooting Guide
Compressor Cycle On High Pressure Control
Possible Cause
Remedy
Main condenser water valve closed or restricted
Open valve to full open position.
Module condenser water isolation valves, if
provided, closed or restricted
Open valves to full open position.
Water regulating valve incorrectly set or
defective
Reset or replace.
Compressor discharge valve partially closed
Open valve to full open position.
Non-condensable gases in hydronic system
Recover non-condensable gases from bleed valve on condenser
or at bleed valve of the building condenser water system.
Overcharge of refrigeration
Recover refrigerant from system while in operation until the first
sign of bubbles are shown in the sight glass. Add back
refrigerant just until bubbles clear.
Condenser water temperature high
Check water supply temperature against requirements; if
cooling tower is used check spray nozzles on cooling tower.
Improper condenser water circulation
Use an ample sized cleanable strainer in the condenser water
circuit; make certain the strainer is clean to insure full flow of
condenser water (strainer must be 60 mesh minimum). It may
sometimes be necessary to treat water to prevent formation of
deposits.
Insufficient water flow through the condenser
Check water flow through condenser against design
requirements.
Fouled condenser brazed plate heat exchanger
Clean-in-place heat exchanger as described in IOM (page 31).
Defective high pressure switch
Replace high pressure switch.
Causes and Prevention of Freeze-Ups
Possible Cause
Remedy
Improper charging
Charge per ClimaCool data plate information, located on the
chiller, following the Superheat and Subcooling procedure
described in IOM (page 25).
Improper chilled water circulation
Use an ample sized cleanable strainer in the chilled water circuit;
make certain the strainer is clean to insure full flow and velocity
of chilled water (strainer screen must be 60 mesh minimum). It
may sometimes be necessary to treat water to prevent
formation of deposits.
Not draining for winter shutdown
When the system is shut down for the winter, remove the drain
plugs from the flush ports
and drain the cooler. Blow out remaining water with air.
Faulty leaving chilled solution temperature
Verify sensor calibration using a calibrated thermometer and
replace if defective.
Wrong freeze-up protection temperature
setpoint
Verify leaving chilled solution freeze protection temperature
setpoint to be set at 8
o
F above solution freeze point.
Note: See page 44 for Troubleshooting for Stainless Steel Strainer ATF Package.
ATTENTION
To avoid the release of refrigerant into the atmosphere, the
refrigerant circuit of this unit must be serviced only by
technicians who meet local, state and federal prociency
requirements.
All refrigerant discharged from this unit must be recovered
WITHOUT EXCEPTION. Technicians must follow industry
accepted guidelines and all local, state and federal statues for
the recovery and disposal of refrigerants.
If a compressor is removed from the unit, system refrigerant
circuit oil will remain in the compressor. To avoid leakage of
compressor oil, the refrigerant lines of the compressor must be
sealed after it is removed.
Disconnect power supply
(ies) before servicing. Refer
servicing to qualied service
personnel. Electric shock
hazard. May result in injury
or death!
Unit to be serviced by
qualied personnel only.
Refrigerant system under
pressure. Relieve pressure
before using torch. Recover
refrigerant and store or
dispose of properly.
Debrancher avant d’entre-
prendre le dépannage de
l’appareil. Consulter un
réparateur qualie pour le
dépannage. Risque de choc
électrique. Résiltat de mai
dans dommages ou la mort!
Conifer la maintenance à
un technicien qualie. Le
systéme frigorique sous
pression. Décomprimer avant
d’exposer à la amme.
Récuperer le frigorigene et
le stocker ou le détrulre
correctement.
WARNING/AVERTISSEMENT
CAUTION/ATTENTION
