Climate Wizard CW-H10 - Inlet Air Filter Assembly

INSTALLATION859736-A AU1007
8
SeeleyInternationalPtyLtd
Inlet AirFilter Assembly
ClimateWizardcoolersaresuppliedex-factorywithanInlet AirFilterassembly.ShouldtheFilter Assemblynotbe
requiredanoptionalSafetyGrilleisavailableandmustbefittedforsafetyreasons.
TheInlet AirFilterassemblyissuppliedinseparatecartonswhenshippedwiththeClimateWizard. Thisrequiresthe
installertoremovethelidofthecooler,removethefiltersfromtheirshippingpositionintheframe,fitthefilterframetothe
cooler,securethecowlingtopandsidestothefilterframeandcooler,slidethefiltersbackintotheframeandsecurethe
cowlingfrontaccesspanelwiththesuppliedfasteners.RefittheLid/Exhaustassemblybackontothecooler,overthe
flangeoftheInletFilterCowling.
Fitfilterframetoinletofcooler
FittheFilterCowlingtopandsides
totheFilterFrameandCooler.
Thetoplipofthefiltercowling(shaded,Fig.3)mustlocateinsidethelidofthecooler(Fig.4),thismayrequirethelidto
beunfastened(ifalreadyassembled)andliftedor,alternately,assemblethelidtothecoolerafterthefilterassemblyand
cowlingisfitted.Insertthefilterstothefilterframe.Fitthefrontpanelofthecowlingontothecowlingassembly.
No. Description
1
2
3
4
5
6
Inlet AirFilterCowling
Inlet AirFilterFrame
AirFilter-Front
AirFilter-LH(CWH-15Only)
AirFilter-Base
AirFilter-RH
1
3 4
2
Inlet AirFiltercomponents
1
2
3
4
5
6
CWH-10
CWH-15
