Climate Wizard CW-H10 - Drain Installation

130DrainOutletposition
145
180
12
SeeleyInternationalPtyLtd
INSTALLATION
DrainInstallation
DRAINVALVE
A built-inDrainValveiscontrolledbythewatermanagementsystem. Thevalvehas1½”(40mm)BSP maleconnection
andisprovidedwithareducingfittingforconnection(ifdesired)toaflexiblehoseforrunningwatertowaste.Seediagram
forlocation.Recommendedminimumdrainhose diameteris¾”(20mm).internal
Thecorrectdrainsystemmustbeused.Waterdrainedfromthedrainvalvemustbecarriedawaytoasuitabledischarge
pointonthebuildingorproperty,inaccordancewithlocalregulations.
ItisarequirementofSeeleyInternational-Neverdrainthewaterdirectlyontotheroof
Drainfittings
location
(Accesspanel
removed,view
fromrearof
cooler)
859736-A AU1007
