ReplacingtheInlet AirFilters
Whenservicingthefiltersthefrontplateofthefiltercowlingmustberemovedtoprovideaccess. Tofitthefiltersintothe
AirFilterframe,slidethebottomfilterintopositionintothebaseoftheframe.Slidethesidefilter(s)intotheframeinthe
samemanner. Tofitthefrontfilter,locatethetopedgeofthefilterunderthetopbracketsandlifttoengagethefilterinside
them. Allowthefiltertodrop,toengagethe2bottombracketsatthebottomoftheframe.
The AirFiltersshouldbereplacedassoonasairflowthroughthefiltersisrestrictedbychokingorcloggingwithdustor
contaminants. Thefrequencyofchangingthefilterisdependantontheairqualityinsitu.
ReplacementInlet AirFiltersareavailablefromSIService AgentsandClimateWizarddistributors.RefertoPage5for
ReplacementPartinformation.
Removescrewstodismantlethe
frontsectionofthefiltercowling,
thelidandsidesofthecowling
remainattachedtothecooler.
Filtersslideintoframechannels
(CWH-10Fit3Filtersonly,omitLHside)
(CWH-15Fit4Filters)
Tofitthefrontfilter,locatethetopedgeofthefilterunderthetopbracketsandlifttoengagethefilter
insidethem. Allowthefiltertodrop,toengagethe2bottombracketsatthebottomoftheframe.
