B-6
Operation
GLC 353/503 MC3
Display 2 The following values are shown
on the display:
- Weld current actual value
- Weld current set value
- stored weld current actual
value achieved during last weld
(highest current output)
The value can be selected with the selector key. LEDs show the values selected.
Operation panel:
Press the selector key to select
the required operation mode.
The active operation mode is
displayed by LED.
The operating modes are
described under Definitions.
Press and hold the selector key for
more than a second; the input mode
changes and you can start
programming (see chapter
Programming).
Operation panel programming:
More
information is in the
Display for operating sequence and weld process job No. chapter Programming
Key +10 (change value in
increments of 10)
Key Up
Key Down
Key Store
Diagram for programming
a job sequence
LED's Selector key
B1.1 Operating and display elements Power source
Operating mode 2 cycle
Operating mode 4 cycle
Oper.mode Super 4 cycle
Operating mode spot weld
Operating mode program
Selector key
