B-34
Programming
GLC 353/503/553 MC3
In the case of locking via key-operated switch, the capacity (the wire feed speed) can be altered
within the set window.
This window is calculated from the standard value of the job and the set percentage value. The
standard value is defined by saving a job (on the power source or remote controller FB1 or FBB1).
Caling up a job on the power source always activates the standard values. If a job is called up via
FB1 or FBB1, the job with the latest setting is always activated.
If the power source has not been locked via key-operated switch, each parameter can be altered
without restriction (not valid for key-operated torches!).
NR:
With this parameter the machine numbers of the power sources can be configured.
This is required if several power sources are connected to one network.
It is important that all power sources connected have different machine numbers because
otherwise the communication with a PC is not possible. The machine number is set with the
arrow keys.
F1:
When you select F1 (key-operated torch), the arrow keys are used to change over between
"ON and "OFF". When a key-operated torch is connected, "ON" must be active.
During normal operation ( — ), the plus/minus keys on the torch are used to alter the energy in the
complete program range. The last welding value set is saved.
The mid-position of the precise adjustment potentiometer has the value "0". The minimum
value of this potentiometer is „-128“, the maximum value „+128“. When the precise
adjustment is altered, the set value (e.g. +50) is shown in the display panel 2 for approx. 3s.
During job operation - e.g. job 01 - the plus/minus keys on the torch can be used to select another
job in the weld pause.
During welding the same plus/minus keys on the torch can be used to alter the energy. The
adjustment range can be determined with the parameter
ADJ. This requires the installation of a
key-operated switch.
The potentiometer "Power" is inactive in this operating mode.
F2:
This paramter can be configured „ON“ or „OFF“.
The control voltages of both potentiometers P1 and P2 can be checked in the case of an "ON"
configuration.
The set control voltage for the capacity is shown on the display panel 1 of the power source.
The set control voltae for the precise adjustment is shown on the display panel 2 of the power
source.
The parameter automatically returns to "OFF" after each new start of the power source ( machine
off/on switch).
F3:
This parameter can also be configured „ON“ or „OFF“.
„OFF“ When the job is changed via remote controller FB1 or FBB1,
the modified values are maintened.
„ON“ When the job is changed via remote controller FB1 or FBB1,
the originally programmed value is used as setting.
